ALBINA AC – 60 WATTS

TLAE060
Truelite Albina Series luminaires are the most advanced roadway lighting fixtures with the best industry lumen efficacy, improved planning, and versatile mounting options. Albina AC – 60 Watts is made in the state of the art manufacturing facilities out of die-casting aluminum alloy housing with a proprietary chromate conversion and electrostatic treatment to withstands high temperature and extreme conditions for increased resistance to corrosion and abrasion.



The IP66 Albina exceeds the standards in energy efficiency, design, optics and the wide options of beam angles makes the best choice for roadway illuminations. Certified UL fixture has all statute requirements for any challenging project requirements.



Scalable modular options include photocell lighting control, smart grid connectivity, wide optics, and beam angle. The Albina AC –60 Watts comes with many accessories for convenient lighting solutions.
Features
Ultra efficient system efficacy of up to 160lm/W

High-quality Osram P3737 High Power LED chips and Inventronics Driver

Multiple beam angles available

Tough IP66 and IK10 construction

Light weight design and Tenon O.D. 42mm or O.D. 60mm. Adjustment range -15° to +15°

AC Street lighting

Albina

30 ~ 480 Watts

Truelite Albina Series luminaires are the most advanced roadway lighting fixtures with the best industry lumen efficacy, improved planning, and versatile mounting options. Albina AC – 100 Watts is made in the state of the art manufacturing facilities out of die-casting aluminum alloy housing with a proprietary chromate conversion and electrostatic treatment to withstands high temperature and extreme conditions for increased resistance to corrosion and abrasion. The IP66 Albina exceeds the standards in energy efficiency, design, optics and the wide options of beam angles makes the best choice for roadway illuminations. Certified UL fixture has all statute requirements for any challenging project requirements. Scalable modular options include photocell lighting control, smart grid connectivity, wide optics, and beam angle. The Albina AC – 100 Watts comes with many accessories for convenient lighting solutions.

LED Lighting
You will find everything here
Product Specification
ALBINA AC – 60W
Light Data
Rated Power60W
Luminous Flux7800 lm
Led ChipOsram P3737 High Power LEDs
No of LEDs1X18
Luminous Efficacy (lm/W)130 lm/W
Color Temperature3000K/4000K/5000K/5700K
CRI>70*
Projected Life-spanL90 B10:>100,000hrs
Optic Lens & Light DistributionUV resistant polycarbonate, discoloration resistant, more weather proof for unique lens design, Optional optics and photometry: 10°, 20°, 30°, 60°, 90°, 120°, 150°,IESNA Type I, II, III, IV, V.
DimmingOptional
Electrical Data
Operating Voltage220-240V~50/60Hz
Drive Current0.86A
Total Harmonic Distortion< 20%
Power Factor(PF)>0.97
Protection class IECClass I
Surge Protection10KV
Service Life100000 Hours
Environmental Data
Working Ambient Temperature-40° to +60°
IP GradeIP66
Relative Humidity(RH)10%-95%
CoolingConventional
CertificateUL/ CUL /DLC/ LM79 / ENEC /CB/CE/ RoHS /PSE /IK10
Mechanical Data
Mech. impact protectionIK10
Product FinishGray/Black/Bronze/White
Housing and heatsinkAluminum alloy
Dimension432*325*108.6
Weight5.0 kg
Luminaire FixingPole top/Tenon mount
*All parameters are measured @ ambient temperature Tc 25 degree
Dimensions
Certifications
IP66
IK10
LM79
LM82
IEC
CE
UL
TUV
CB
RoHS
ENEC
