Battery Banks 24V I 90Ah
TLLFP2490
LFP- TLLFP2490 batteries from Truelite is designed for challenging energy storage applications with cutting-edge advanced BMS to ensure the perfect combination of Lithium battery chemistry. Truelite has put in vast experience and research in developing the LFP line of energy storage batteries manufactured in world-class facilities with high quality and safety standards.
Truelite LFP batteries are lightweight with high energy and power density making them the most reliable solution for space-critical applications and for use in extreme high-temperature conditions.
Truelite LFP- TLLFP2490 series uses the best LiFePO4 battery chemistry cylindrical cells with an advanced battery management system to ensure fast charging and stable discharging making the right energy storage solution for PV applications, especially grid applications.
Truelite LFP batteries are lightweight with high energy and power density making them the most reliable solution for space-critical applications and for use in extreme high-temperature conditions.
Truelite LFP- TLLFP2490 series uses the best LiFePO4 battery chemistry cylindrical cells with an advanced battery management system to ensure fast charging and stable discharging making the right energy storage solution for PV applications, especially grid applications.
Features
Excellent float & Superior Lifecycle
Zero gas emissions
Zero maintenance
Reduced weight and pack size
Decreased facility footprint cost
System data recording and detailed performance status indicators optional
Superior Resilience
Wide operating temperature range without thermal runaway
Low self-discharge and low operating costs due to higher energy efficiency
Accessories
Battery Bank
Battery Banks
LiFePO4
Energy Storage
Lithium-ion Phosphate LFP
Product Specification
| Battery Banks 24V I 90Ah | |
|---|---|
| Product Specifications | |
| Model Number | TLLFP2490 |
| Nominal Voltage | 24V |
| Nominal Capacity | 90Ah |
| Minimum Capacity | 89.2Ah |
| Energy | 2160Wh |
| Resistance | <_65mΩ |
| Efficiency | 90% |
| Self Discharge | <4% per Month |
| Charge Voltage | 25.2V |
| Discharge Specifications | |
| Maximum Discharge Current | 7000mA |
| Standard Discharge Current | 4000mA |
| Discharge Cut-Off Voltage | 18.0V |
| Open Voltage | 20.0V~24.0V |
| Over Discharge Protection Voltage | 2.4V±0.05V |
| Over Charge Protection Voltage | 4.35V±0.025V |
| Over Current Protection | 10.0 ~18.0A |
| Temperature Specification | |
|---|---|
| Operating Temperature | -20 ~+60˚C |
| Atmosphere pressure | 86~106kPa |
| Storage Temperature | -20 to +60˚C |
| High Temperature | 55±2˚C |
| Mechanical Specifications | |
| Enclosure Protection | IP56 |
| Cell Type | 90000mAh/3.7V |
| Dimensions (L x W x H) | 270X250X83 |
| Weight | 10.5Kg |
| Charge Specifications | |
| Recommended Charge Current | 20A |
| Maximum Charge Current | 60A |
| Charge Current Cut-Off | 1000A (±100A) |
| Recommended Charge Voltage | 20.8V~24.0V |
| *All parameters are measured @ ambient temperature Tc 25 degree | |
