LiFePO4-24V I 85Ah
TLLFP2485
LFP – TLLFP2485 batteries from Truelite is designed for challenging energy storage applications with cutting-edge advanced BMS to ensure the perfect combination of Lithium battery chemistry. Truelite has put in vast experience and research in developing the LFP line of energy storage batteries manufactured in world-class facilities with high quality and safety standards.
Truelite LFP- TLLFP2485 batteries are lightweight with high energy and power density making them the most reliable solution for space-critical applications and for use in extreme high-temperature conditions.
Truelite LFP series uses the best LiFePO4 battery chemistry cylindrical cells with an advanced battery management system to ensure fast charging and stable discharging making the right energy storage solution for PV applications, especially grid applications.
Truelite LFP- TLLFP2485 batteries are lightweight with high energy and power density making them the most reliable solution for space-critical applications and for use in extreme high-temperature conditions.
Truelite LFP series uses the best LiFePO4 battery chemistry cylindrical cells with an advanced battery management system to ensure fast charging and stable discharging making the right energy storage solution for PV applications, especially grid applications.
Features
Excellent float & Superior Lifecycle
Zero gas emissions
Reduced weight and pack size
Decreased facility footprint cost
System data recording and detailed performance status indicators optional
Superior Resilience
Wide operating temperature range without thermal runaway.
Low self-discharge and low operating costs due to higher energy efficiency
Battery Bank
Battery Banks
LiFePO4
Energy Storage
Lithium-ion Phosphate LFP
Product Specification
| Product Specifications | |
|---|---|
| Model Number | TLLFP2485 |
| Nominal Voltage | 24V |
| Nominal Capacity | 85Ah |
| Capacity @ 25A | 360 min |
| Energy | 1800Wh |
| Resistance | 30 mΩ |
| Efficiency | 99% |
| Self Discharge | <3% per Month |
| Maximum Modules in Series | 1 |
| Discharge Specifications | |
| Maximum Continuous Discharge Current | 50A |
| Peak Discharge Current | 800A (2 s) |
| PCM Discharge Current Cut-off | 1000A (±100A) |
| Recommended Low Voltage Disconnect | 11V |
| PCM Discharge Voltage Cut-off | 9.2V |
| Short Circuit Protection | 200~600μs |
| Temperature Specification | |
| Discharge Temperature | -4 to 140˚F (-20 to 60˚C) |
| Charge Temperature | 32 to 131˚F (0 to 55˚C) |
| Storage Temperature | -4 to 140˚F (-20 to 60˚C) |
| PCM High Temperature Cut-off | 176˚F (80˚C) |
| PCM Charge Voltage Cut-off | 15.4V |
| Reconnect Voltage | 14.6V |
| Balancing Voltage | 14.4 V |
| Mechanical Specifications | |
|---|---|
| Dimensions (L x W x H) | 525x2698x220mm |
| Weight | 57.3202lbs (26kg) |
| Terminal Type | M8 |
| Terminal Torque | 80-100 in-lbs (9-11 N-m) |
| Case Material | ABS |
| Enclosure Protection | IP56 |
| Cell Type - Chemistry | Cylindrical - LiFePO4 |
| Charge Specifications | |
| Recommended Charge Current | 50A |
| Maximum Charge Current | 120A |
| PCM Charge Current Cut-off | 1000A (±100A) |
| Recommended Charge Voltage | 14.2V~14.6V |
| Compliance Specifications | |
| Certifications | CE (battery) UL1642 & IEC62133 (cells) |
| Shipping Classification | UN 3480, CLASS 9 |
| *All parameters are measured @ ambient temperature Tc 25 degre | |
